IBM EM6U 256GB DDR4 Memory for Power10 S1024
The IBM EM6U is a 256 GB DDR4 memory feature for the IBM Power S1024. It consists of two 128 GB full-height DDIMMs.
Product Description
The IBM EM6U (feature code EM6U, part number 01GY917, CCIN 32AD) is a 256 GB memory feature made of two 128 GB full-height DDR4 DDIMMs. Each module uses 16 Gb DRAM. The feature uses two DDIMM slots and is the full-height (4U) 128 GB module for the Power S1024 9105-42A. Do not mix this DDR4 feature with DDR5 memory in the same system. Full-height memory is not supported on systems that have an RDX drive.
Features
- 256 GB capacity from two 128 GB DDIMMs
- DDR4 full-height (4U) form factor
- 16 Gb DRAM
- CCIN 32AD
- Supported on Power S1024 9105-42A
- Installs in pairs
Technical Specifications
- Feature Code: EM6U
- Part Number: 01GY917
- CCIN: 32AD
- Capacity: 256 GB (2 × 128 GB)
- DRAM: 16 Gb DDR4
- Form Factor: Full-height DDIMM
- Slots Used: 2
Compatibility
The IBM EM6U 256GB DDR4 Memory is compatible with:
- Systems: IBM Power S1024 9105-42A. Also supported on related 4U Power10 systems that accept full-height DDR4 DDIMMs, including Power L1024 9786-42H
- Operating systems: IBM i, AIX, VIOS, and Linux on Power
- Related features: EM6N (32 GB), EM6W (64 GB), and EM6X (128 GB) are the low-profile DDR4 features. EM78 is the 512 GB full-height DDR4 feature
- Limitations: Requires two empty DDIMM slots. Full-height memory is not supported when an RDX drive is installed. Do not mix DDR4 and DDR5 in the same system. All memory in the system must be the same height. Follow the system memory plugging rules
Warranty
This product comes with a 60-day warranty covering parts and functionality.
