Product Description
Lenovo ThinkSystem SR650a V4 64-Core AI Server
Lenovo ThinkSystem SR650a V4 2U AI Server – Dual GPU Configuration
The Lenovo ThinkSystem SR650a V4 is a 2U rack server optimized for AI workloads, configured with dual Intel Xeon 6530P processors for a total of 64 cores. This system includes 512 GB of TruDDR5 memory, dual NVIDIA RTX PRO 6000 Blackwell Server Edition 96GB GPUs, and NVMe storage, making it well suited for AI inference, generative AI, and accelerated computing applications.
This configuration uses the SR650a V4 chassis with NVMe backplane support, dual 3200W Titanium power supplies, a BlueField-3 networking adapter, and high-performance cooling for the GPUs. It ships with a 3-year base warranty plus Premier 24x7 4-hour response coverage and includes NVIDIA AI Enterprise and Red Hat AI Enterprise support.
Configuration Highlights
- Dual Intel Xeon 6530P processors (32 cores each, 2.3 GHz, 225W)
- 512 GB TruDDR5 6400 MHz memory (16 × 32 GB)
- Dual NVIDIA RTX PRO 6000 Blackwell Server Edition 96GB PCIe Gen5 GPUs
- 7.68 TB raw NVMe storage (2 × 3.84 TB Read Intensive PCIe 5.0 U.2 SSDs)
- 2 × 960 GB M.2 NVMe SSDs for boot
- NVIDIA BlueField-3 B3220 200G networking adapter with NDR/NDR200 transceivers
- Broadcom 5719 1GbE 4-port OCP Ethernet adapter
- Dual 3200W Titanium hot-swap power supplies
- High-performance fan modules for 600W GPU support
- TPM 2.0 and XClarity management
- 3-year Premier 24x7 4-hour response + KYD add-on
- NVIDIA AI Enterprise subscription (2 GPUs) and Red Hat AI Enterprise support (3 years)
Key Features
- 2U form factor optimized for dual high-end GPUs
- Latest Intel Xeon 6 processors with strong AI inference performance
- Dual NVIDIA RTX PRO 6000 Blackwell GPUs for accelerated computing
- High-bandwidth NVMe storage and M.2 boot drives
- Advanced networking with BlueField-3 for high-speed connectivity
- Redundant high-capacity power supplies
- XClarity Controller for remote management and monitoring
- Long-travel tool-less rail kit included
- ENERGY STAR certified configuration
Technical Specifications
| Component | Details |
|---|---|
| Model | ThinkSystem SR650a V4 |
| Form Factor | 2U rack |
| Processors | 2 × Intel Xeon 6530P (32 cores, 2.3 GHz, 225W) |
| Total Cores | 64 |
| Memory | 512 GB (16 × 32 GB TruDDR5 6400 MHz RDIMM) |
| GPUs | 2 × NVIDIA RTX PRO 6000 Blackwell Server Edition 96GB |
| Storage | 2 × 3.84 TB Read Intensive NVMe PCIe 5.0 U.2 SSDs (7.68 TB raw) + 2 × 960 GB M.2 NVMe |
| Networking | NVIDIA BlueField-3 B3220 200G + Broadcom 5719 1GbE 4-port OCP |
| Power Supplies | 2 × 3200W Titanium CRPS hot-swap |
| Fans | 6 × ThinkSystem 2U 6056 24K Ultra Fan Modules (for 600W adapters) |
| Management | XClarity Controller with Platinum upgrade |
| Security | TPM 2.0 |
| Rails | ThinkSystem Long Travel Toolless Slide Rail Kit V4 |
| Software | NVIDIA AI Enterprise (2 GPUs) + Red Hat AI Enterprise (3 years) |
| Warranty | 3-year base + Premier 24x7 4Hr response + KYD add-on |
Compatibility
This Lenovo ThinkSystem SR650a V4 configuration supports Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, and VMware ESXi. The included NVIDIA AI Enterprise and Red Hat AI Enterprise subscriptions provide software support optimized for AI workloads for three years.
Data Tech configures and tests this system for reliability. The server includes the listed warranty and support coverage. Contact our specialists for additional configuration options or questions about this SR650a V4 system.
