Product Description
Lenovo ThinkSystem SR650 V4 16-Core 2U Server
Lenovo ThinkSystem SR650 V4 2U Rack Server – 16-Core Configuration
The Lenovo ThinkSystem SR650 V4 is a versatile 2U rack server configured with dual Intel Xeon 6714P processors for a total of 16 cores. This system includes 512 GB of TruDDR5 memory and 19.2 TB of mixed-use NVMe storage, providing strong capacity for virtualization, databases, and mixed enterprise workloads.
This configuration uses the ThinkSystem SR650 V4 24x2.5" chassis with dual NVMe backplanes, dual 1300W Platinum power supplies, and dual Mellanox ConnectX-6 Lx 10/25GbE OCP adapters. It ships with a 3-year base warranty plus Premier next-business-day response coverage and includes Red Hat Enterprise Linux subscription with Lenovo support.
Configuration Highlights
- Dual Intel Xeon 6714P processors (8 cores each, 4.0 GHz, 165W)
- 512 GB TruDDR5 6400 MHz memory (8 × 64 GB)
- 19.2 TB raw NVMe storage (6 × 3.2 TB Mixed Use PCIe 5.0 U.2 SSDs)
- 2U form factor with 24 × 2.5" chassis
- Dual Mellanox ConnectX-6 Lx 10/25GbE SFP28 2-port OCP Ethernet adapters
- Dual 1300W Platinum hot-swap power supplies
- TPM 2.0 and XClarity management
- 3-year Premier NBD response + KYD add-on
- Red Hat Enterprise Linux 2-socket subscription with Lenovo support (3 years, up to 4 virtual nodes)
Key Features
- 2U design with strong storage and expansion capacity
- Latest-generation Intel Xeon 6 processors
- PCIe 5.0 NVMe storage for high performance
- Dual high-speed networking adapters
- Redundant power supplies for improved availability
- XClarity Controller for remote management and monitoring
- Tool-less rail kit included for standard racks
- ENERGY STAR certified configuration
Technical Specifications
| Component | Details |
|---|---|
| Model | ThinkSystem SR650 V4 |
| Form Factor | 2U rack |
| Processors | 2 × Intel Xeon 6714P (8 cores, 4.0 GHz, 165W) |
| Total Cores | 16 |
| Memory | 512 GB (8 × 64 GB TruDDR5 6400 MHz RDIMM) |
| Storage | 6 × 3.2 TB Mixed Use NVMe PCIe 5.0 U.2 SSDs (19.2 TB raw) |
| Backplanes | 2 × ThinkSystem 2U V4 8×2.5" NVMe |
| Networking | 2 × Mellanox ConnectX-6 Lx 10/25GbE SFP28 2-port OCP Ethernet adapters |
| Power Supplies | 2 × 1300W Platinum CRPS hot-swap |
| Fans | 6 × ThinkSystem 2U 6056 20K Performance Fan Modules |
| Management | XClarity Controller with Platinum upgrade |
| Security | TPM 2.0 |
| Rails | ThinkSystem Toolless Slide Rail Kit V4 |
| Operating System | Red Hat Enterprise Linux (2-socket subscription included, 3 years, up to 4 virtual nodes) |
| Warranty | 3-year base + Premier NBD response + KYD add-on |
Compatibility
This Lenovo ThinkSystem SR650 V4 configuration supports Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, and VMware ESXi. The included Red Hat subscription provides operating system licensing and Lenovo support for three years.
Data Tech configures and tests this system for reliability. The server includes the listed warranty and support coverage. Contact our specialists for additional configuration options or questions about this SR650 V4 system.
