Product Description
IBM 5782 PCI-X EXP24 Controller 1.5GB No IOP
The IBM 5782 is a PCI-X EXP24 disk controller with 1.5 GB compressed write cache that attaches TotalStorage EXP24 disk enclosures without requiring an IOP.
Product Description
The IBM 5782 PCI-X EXP24 Controller provides an EXP24 disk controller with PCI-X DDR technology. It has a maximum of 1.5 GB compressed write cache and a maximum of 1.6 GB compressed read cache. The controller supports RAID-5 and RAID-6. Mirroring is supported via IBM i. It includes embedded auxiliary write cache and concurrent battery maintenance. The controller is implemented using two physical cards that are firmly connected and requires two adjacent PCI slots. It provides three Ultra320 SCSI ports for attachment of disk drives in a 5786 or 5787 TotalStorage EXP24 Disk Drawer. This feature includes a double-wide blind swap cassette required for placement in a Power 570, 770, 780 system unit or 5790 I/O drawer. Feature 5782 indicates IOP-less operation. The CCIN is 571F / 575B.
Features
- 1.5 GB compressed write cache
- 1.6 GB compressed read cache
- RAID-5 and RAID-6 support
- Three Ultra320 SCSI ports
- Embedded auxiliary write cache
- Concurrent battery maintenance
- Double-wide blind swap cassette included
- IOP-less operation
- Requires two adjacent PCI-X slots
Technical Specifications
- Feature Code: 5782
- CCIN: 571F / 575B
- Write Cache: 1.5 GB compressed
- Read Cache: 1.6 GB compressed
- RAID Levels: RAID-5, RAID-6
- SCSI: Three Ultra320 ports
- Form Factor: Double-wide (two adjacent PCI-X slots)
- Enclosure: Includes double-wide blind swap cassette
Compatibility
The IBM 5782 PCI-X EXP24 Controller is compatible with:
- Systems: IBM Power6 and Power7 servers including 8202-E4B, Power 570, 770, and 780; 5790 I/O drawer
- Operating Systems: IBM i 6.1 and 7.1 at supported levels
- Storage: 5786 and 5787 TotalStorage EXP24 Disk Drawers; 5796 PCI-DDR 12X Expansion Drawer
- Limitations: Requires two adjacent long PCI-X slots. Both slots must be assigned to the same partition. Confirm cassette and placement requirements for the target system
Warranty
This product comes with a 60-day warranty covering parts and functionality.
