Product Description
IBM S1014 9105-41B AIX Power10 24-Core Server
The IBM S1014 9105-41B is a high-performance 1U Power10 rack server optimized for demanding AIX and Linux workloads. With a 24-core POWER10 processor, high-speed NVMe storage, and enterprise-grade features, it delivers exceptional scalability and efficiency for database, virtualization, ERP, and cloud-native applications in a compact footprint.
Product Description
The IBM S1014 9105-41B AIX Power10 24-Core Server comes pre-configured with a 24-core POWER10 processor (3.0–3.9 GHz), 256 GB DDR5 memory, 6.4 TB raw Enterprise NVMe storage (8 × 800 GB U.2 SSDs with mirroring), AIX 7.3+ support, PowerVM Enterprise Edition, dual redundant power supplies, 4-port 1 GbE adapter, and a complete set of enterprise features. The server uses the EJSE storage backplane with eight NVMe U.2 drive slots and supports hot-plug components for maximum uptime.
Features
- 24-core POWER10 processor (3.0–3.9 GHz)
- 256 GB DDR5 memory (scalable to higher capacities)
- 6.4 TB raw Enterprise NVMe storage (8 × 800 GB U.2 SSDs, mirrored)
- PowerVM Enterprise Edition for virtualization
- Dual 1200W AC Titanium power supplies with redundant power cords
- 4-port 1 GbE adapter and system console Ethernet LAN adapter
- Operator panel LCD display and front NVMe bezel
- Hot-plug NVMe bays and concurrent maintenance support
Priced Configuration –
| Feature Code | Description |
|---|---|
| 9105-41B | IBM Power S1014 Server |
| 0265 | AIX Partition Specify |
| 2146 | Primary OS - AIX |
| 4650 | Rack Indicator - Not Factory Integrated |
| 6458 | Power Cord 4.3m, Drawer to IBM PDU (250v/10A) (QTY=2) |
| 9300 | Language Group Specify – US English |
| 9440 | New AIX License Core Counter (QTY=24) |
| AKCH | Standard S&H Indicator |
| ALH0 | Expert Care Indicator |
| EB3W | AC Titanium Power Supply – 1200W (100-127V/200-240V) (QTY=2) |
| EHSD | Power AIX Segment Indicator |
| EJ1Y | Storage backplane with eight NVMe U.2 drive slots |
| EJXU | Front IBM Bezel for 16 NVMe-bays BackPlane Rack-Mount |
| EMFA | 64 GB (2×32GB) DDIMMs, 3200 MHz 16Gbit DDR5 Memory (QTY=2) |
| EN2W | 4-Port 10GbE Adapter BaseT RJ45 Adapter |
| EPFZ | One Processor Core Activation for EPH8 (QTY=24) |
| EPH8 | 24-core Typical 2.75 to 3.90 GHz Power10 Processor |
| EPVT | PowerVM v4 (QTY=24) |
| ERBZ | Single Bulk Packaging Specify |
| ES5C | Enterprise 1.6 TB SSD PCIe4 NVMe U.2 module for AIX/Linux (QTY=2) |
| ESWK | AIX Update Access Key (UAK) (QTY=39) |
| EU0K | Operator Panel LCD Display |
| EXA3 | 3-Year Advanced Expert Care |
Compatibility
The IBM S1014 9105-41B AIX Power10 24-Core Server is compatible with:
- Operating Systems: AIX 7.3+, Linux (RHEL/SUSE/Ubuntu), VIOS
- Storage/Expansion: Additional NVMe U.2 drives in the 8-bay backplane
- Networking: Built-in 4-port 1 GbE + optional PCIe adapters
- Limitations: 24-core configuration optimized for medium to large AIX and Linux workloads
Verify exact configuration, firmware levels, and entitlement requirements via IBM documentation for your specific Power Systems model.
Warranty
This product comes with a 60-day warranty covering parts and functionality.
Ready to Order This Affordable Power10 Server?
Data Tech Computer Services, Inc. Call 770-772-0200 or email sales@datatechcomputer.com IBM Business Partner since 1994 – Installation, migration and support available.
