Product Description
The IBM EC66 PCIe4 2-port 100Gb ROCE EN Adapter (Feature Code: EC66) is a high-performance solution for IBM Power Systems. With CCIN 2CF3, it provides reliable server network connectivity for enterprises.
Technical Specifications
- Feature Code: EC66
- Part Number: Not specified
- CCIN: 2CF3
- Interface: PCIe Gen4 x16
- Ports: Two 100 GbE QSFP28
- Standards: NIC, IBTA RoCE
- Form Factor: Full-height
- Features: TCP/UDP/IP offload, LSO, LRO, NIM boot
- Warranty: 60-day
- Supported Systems: Power8, Power9
System Compatibility
The EC66 adapter (EC66, CCIN 2CF3) requires a PCIe Gen4 x16 slot in Power8 or Power9 systems for high-performance server network operations.
- Supported Systems:
- Power8: 8286-41A (S814), 8286-42A (S824)
- Power9: 9009-41A (S914), 9009-42A (S924), 9223-42H (H924)
- Operating System: IBM i 7.3 TR6+ or 7.4+; AIX 7.2 TL3+; Linux RHEL 8.2+, SLES 15 SP2+; VIOS 2.2.6.40+.
- Requirements: Firmware 930+, QSFP28 cables (e.g., #EB5J).
- Restrictions:
- Compatible with Power8+ systems only.
- Incompatible with Power7, Storwize.
- SR-IOV requires specific OS levels.
- Refurbished condition only.
