    • Power 8 AIX

    Drives for Power8 AIX

    The IBM Power8 Disk Drives (AIX) category includes enterprise-grade SAS HDDs (10K/15K RPM) and SAS SSDs (mainstream read-intensive and enterprise mixed-use classes) qualified for AIX workloads on Power8 servers. Power8 systems (e.g., S814, S822, S824, E870, E880) support internal SFF-3 bays (typically 8–18) with SAS drives via integrated RAID controllers or backplanes (#EJ0N series), plus external EXP24S/EXP24SX drawers for additional SAS capacity. Capacities range from 300 GB (HDD) to 3.84 TB+ (SSD), with hot-swap SFF-3 carriers, full RAID support (0/1/5/6/10), and native AIX compatibility (7.1+). NVMe was not supported internally on Power8 (introduced in Power9); all direct-attached storage uses SAS.

    Product Description

    IBM Power8 Disk Drives for AIX provide reliable, high-availability internal and expandable storage optimized for AIX environments on Power8 servers. SAS HDDs (2.5-inch SFF-3, 12 Gb/s or 6 Gb/s) deliver proven 10K/15K RPM performance for transactional, database, ERP, and mixed I/O workloads, while SAS SSDs (mainstream and enterprise variants) offer dramatically higher IOPS and lower latency for virtualization, analytics, high-concurrency applications, and AIX-based enterprise workloads. Drives use IBM feature codes (#59xx series for HDDs, #ESxx series for SSDs) with sector formats supporting AIX native attachment (512e/4Kn). Power8 supports internal SFF-3 bays via backplanes (#EJ0N/EJ0P/EJ0S series) and external EXP24S drawers (#5887) for SAS expansion. All drives are IBM-qualified for endurance, power-loss protection (on SSDs), firmware alignment, and seamless integration with AIX mirroring, journaling, RAID (via integrated controllers or VIOS), and PowerVM virtualization. Power8 relies entirely on SAS storage (no internal NVMe support; NVMe introduced in Power9).

    Features

    • SAS HDDs: 10K/15K RPM for high-throughput random I/O, capacities 300 GB–1.8 TB+, RAID 0/1/5/6/10 support.
    • SAS SSDs: Mainstream (read-intensive) and enterprise (mixed-use) variants, high endurance (1–10 DWPD), capacities 387 GB–3.84 TB+, 512e/4Kn sector support for AIX.
    • Form factors: 2.5-inch SFF-3 (primary internal), 3.5-inch LFF via external drawers.
    • Hot-plug SFF-3 carriers with blind-swap capability.
    • Encryption options (select SSDs), T10 DIF/DIX end-to-end protection.
    • Expansion: EXP24S (#5887) adds 24 SFF SAS bays.
    • No internal NVMe support on Power8; SAS-only for direct-attached storage.

    Technical Specifications

    Specifications vary by feature code and Power8 model (S814/S822/S824, E870/E880). Common types:

    Type Form Factor Interface Capacities (Typical) RPM / Endurance Notes / AIX Support
    SAS HDD 2.5" SFF-3 12 Gb SAS 300 GB – 1.8 TB 10K / 15K High-performance transactional
    SAS HDD 3.5" LFF 12 Gb SAS 4 TB – 10 TB+ 7.2K Capacity-focused (external drawers)
    SAS SSD 2.5" SFF-3 12 Gb SAS 387 GB – 3.84 TB+ 1–10 DWPD Mainstream/enterprise, AIX native
    • Latency: SAS SSD ~100–200 μs typical.
    • IOPS: SAS SSD hundreds of thousands per system.
    • Sector Formats: 512e/4Kn for AIX native.
    • Expansion: EXP24S (24 SFF bays SAS).

    Featured Example Listings

    Compatibility

    IBM Power8 Disk Drives for AIX are qualified for:

    • Power8 Models: S814 (8286-41A), S822/S824 (8284-22A), E870/E880 (9119-MME/MHE), and related scale-out/enterprise servers.
    • Operating Systems: AIX 7.1+ (full support), VIOS, Linux (RHEL/SUSE), IBM i 7.1+ (cross-compatible drives).
    • Attachment: SAS via integrated backplanes (#EJ0N/EJ0P/EJ0S series); external EXP24S drawers (#5887).
    • Adapters/Controllers: Integrated SAS RAID (with/without cache); no NVMe support internally.
    • Legacy SAS: Fully supported; all internal storage is SAS-based.

    Verify exact feature codes, CCINs, firmware levels, and backplane options via IBM Sales Manual or resources for your Power8 model and AIX version.

    Warranty

    This product comes with a 60-day warranty covering parts and functionality.
