Product Description
IBM 6807 4.19 GB DASD
The IBM 6807 is a 4.19 GB 7,200 RPM Ultra SCSI hard disk drive in a 3.5-inch form factor for IBM AS/400 9406 systems.
Product Description
The IBM 6807 (feature code #6807) provides a 3.5-inch single disk unit with 4.19 GB (approximately 4,194 MB) capacity and a 7,200 RPM spindle speed using an Ultra SCSI interface. It is a 2-byte disk unit designed for AS/400 9406 Models 170, 600, 620, and 720. The drive is supported in the system unit or the #9364 System Unit Expansion. Average seek time is approximately 8.3 ms with 4.17 ms average latency and a data rate up to 40 MB/s. The drive includes a 512 KB cache. It is a customer-installable feature on applicable models and requires a disk unit slot and controller.
Features
- 4.19 GB storage capacity
- 7,200 RPM rotation speed
- Ultra SCSI interface
- 3.5-inch form factor
- 2-byte disk unit
- Approximately 8.3 ms average seek time
- 512 KB cache
- Supported on 9406 Models 170, 600, 620, and 720
Technical Specifications
- Feature Code: 6807
- Capacity: 4.19 GB (4,194 MB)
- Rotation Speed: 7,200 RPM
- Interface: Ultra SCSI
- Form Factor: 3.5-inch
- Cache: 512 KB
- Average Seek Time: ~8.3 ms
- Average Latency: 4.17 ms
- Data Rate: Up to 40 MB/s
- Type: Hard Disk Drive (HDD)
- Byte Type: 2-byte
- Supported Models: 9406-170, 9406-600, 9406-620, 9406-720
Compatibility
The IBM 6807 4.19 GB DASD is compatible with:
- Systems: IBM AS/400 9406 Models 170, 600, 620, and 720
- Enclosures: System unit or #9364 System Unit Expansion with available disk slots
- Operating Systems: Supported OS/400 levels for the host 9406 system
- Notes: Requires available disk unit slot and controller. Customer-installable on applicable models. Verify model-specific support and configuration limits.
Warranty
This product comes with a 60-day warranty covering parts and functionality.
