Product Description
The IBM EJ1D Backplane with 18 SFF-3 Bays (Part Number: 01DH407) is a high-performance storage solution for IBM Power9 Systems. Featuring dual 57D8 SAS controllers, this CCIN 2D35 backplane provides reliable storage connectivity for enterprise environments.
Technical Specifications
- Part Number: 01DH407
- Feature Code: EJ1D
- CCIN: 2D35
- Bays: 18 SFF-3 SAS
- Controllers: Dual 57D8 6Gb SAS RAID
- Write Cache: 1.8GB (up to 7.2GB with compression)
- RAID Levels: RAID-0, 5, 6, 10, 5T2, 6T2, 10T2
- External Ports: Optional EJ0W for EXP24S/EXP24SX
- Warranty: 60-day for reliability
- Supported Systems: 9009-41A, 9009-42A, 9223-42H
System Compatibility
The EJ1D backplane (01DH407, CCIN 2D35) requires SFF-3 bays in Power9 system units and specific operating systems for high-performance storage operations.
- Supported Systems:
- Power9: 9009-41A (S914), 9009-42A (S924), 9223-42H (H924)
- Operating System: IBM i V7R3 with TR4 or V7R4; AIX 7.2+; Linux RHEL 7.6+, SLES 12 SP4+; VIOS.
- Drive Requirements: 5xx or 4k byte sectors; no mixing in RAID arrays.
- Restrictions:
- Fits SFF-3 bays in Power9 system units only.
- No split backplane; use EJ1C or EJ1E.
- EJ0W ports require PCIe3 x8 slot.
- Refurbished condition only.
