Product Description
The IBM EJ1C Backplane with 12 SFF-3 Bays (Part Number: 01DH486) is a high-performance storage solution for IBM Power9 Systems. Featuring an integrated 6Gb SAS RAID controller, this CCIN 6B64 backplane provides reliable storage connectivity for enterprise environments.
Technical Specifications
- Part Number: 01DH486
- Feature Code: EJ1C
- CCIN: 6B64
- Bays: 12 SFF-3 SAS, 1 RDX
- Controller: Integrated 6Gb PCIe3 SAS RAID
- RAID Levels: RAID-0, 5, 6, 10
- Split Backplane: Supported with EJ1E
- Write Cache: None
- Warranty: 60-day
- Supported Systems: 9009-41A, 9009-42A, 9223-42H
System Compatibility
The EJ1C backplane (01DH486, CCIN 6B64) requires SFF-3 bays in Power9 system units and specific operating systems for high-performance storage operations.
- Supported Systems:
- Power9: 9009-41A (S914), 9009-42A (S924), 9223-42H (H924)
- Operating System: IBM i V7R3 with TR4 or V7R4; AIX 7.2+; Linux RHEL 7.6+, SLES 12 SP4+; VIOS.
- Drive Requirements: 5xx or 4k byte sectors; no mixing in RAID.
- Restrictions:
- Fits SFF-3 bays in Power9 system units only.
- No write cache; use EJ1D or EJ1M.
- Split backplane with EJ1E.
- Refurbished condition only.
