Product Description
IBM 8231-E1C Power 710 Express Server for iSeries EPC1
The IBM 8231-E1C Power 710 Express (EPC1 configuration) is a compact, entry-level 1U rack or tower server from the Power7 generation, specifically designed and certified for IBM i (iSeries) workloads. It provides a cost-effective, reliable platform for small to medium businesses running IBM i applications, including ERP, databases, file serving, and web hosting.
Powered by a single POWER7 processor (up to 4 cores), the server supports up to 64 GB of DDR3 memory and integrated storage controllers with RAID 5/6/10 options. It includes embedded 4-port 1 GbE networking and optional high-speed I/O expansion, making it suitable for consolidated workloads or as a dedicated IBM i partition in larger Power environments.
With full IBM i certification, the 8231-E1C supports OS/400 V6R1 through IBM i 7.3 (with appropriate PTFs and firmware), enabling legacy modernization while maintaining compatibility with traditional green-screen applications, RPG/COBOL programs, and DB2 for i databases. It offers excellent RAS features including hot-plug components and redundant power options for high availability in production settings.
The IBM 8231-E1C Power 710 Express Server for iSeries (EPC1) is backed by a 60-day warranty, providing assurance in its quality and operation.
Key Features
- Single-socket POWER7 processor with up to 4 cores.
- Up to 64 GB DDR3 memory (ECC protected).
- Integrated SAS/SATA storage controller with RAID 5/6/10 support.
- Embedded 4-port 1 GbE networking.
- Full IBM i certification (V6R1 through IBM i 7.3).
- 1U rack
- Hot-plug disk bays and redundant power options.
- Optimized for small to medium IBM i workloads (ERP, databases, file/print serving).
Specifications
| Attribute | Specification |
|---|---|
| Model | 8231-E1C (EPC1 configuration) |
| Form Factor | 1U rack-mount or tower (with optional cover) |
| Processor | Single POWER7 (up to 8 cores, SMT-4) |
| Memory | Up to 64 GB DDR3 (ECC) |
| Storage Bays | Up to 6 SFF (2.5-inch) SAS/SATA hot-plug bays |
| Storage Controller | Integrated SAS with RAID 0/5/6/10 |
| Networking | Embedded 4-port 1 GbE |
| PCIe Slots | Up to 3 PCIe Gen2 slots |
| Power Supplies | Single or redundant hot-swap (model-dependent) |
| Operating Systems | IBM i (V6R1 through 7.1), AIX 6.1/7.1, Linux (RHEL 5/6, SLES 10/11) |
| Warranty | 60 days |
Compatibility
The IBM 8231-E1C Power 710 Express (EPC1) is compatible with legacy IBM i and Power Systems environments:
- Operating Systems: IBM i (V6R1 through 7.3 with appropriate PTFs), AIX 6.1/7.1, Linux distributions certified for POWER7.
- Applications: Traditional IBM i workloads (RPG, COBOL, DB2 for i), ERP (JD Edwards, Infor, MAPICS), file/print serving.
