Product Description
IBM 5260 PCIe2 LP 4-port 1GbE Adapter
The IBM 5260 PCIe2 LP 4-port 1GbE Adapter provides reliable, high-speed network connectivity for Power7 systems. This low-profile adapter supports four 1Gb Ethernet ports configurable to 1000, 100, or 10 Mbps, using 4-pair CAT-5 UTP cables up to 100 meters.
Key Features
- 4 ports for expanded connectivity
- 1 Gbps speeds with auto-negotiation
- PCI Express 2.0 interface
- Support for VLANs and large-send off-load
- Compliance with IEEE 802.3ab and 802.3u
- Low-profile design for flexible installation
Specifications
| Attribute | Details |
|---|---|
| Feature Code (FC) | 5260 |
| CCIN | 576F |
| FRU Number | 74Y4064 |
| I/O Bus | PCI-Express 2.0 |
| Connector | RJ45 |
| Cable Type | 4-pair CAT-5 UTP, up to 100 m |
| Standards | IEEE 802.3ab, 802.3u |
| Operating Systems | AIX 5.3 or later, Red Hat Enterprise Linux 5.6 or later, SUSE Linux Enterprise Server 11 SP1 or later, IBM i 6.1 or later |
Compatibility
This adapter is designed for use with various IBM Power7 models, ensuring broad system integration:
- 8231-E2B, 8231-E1C, 8231-E1D, 8231-E2C, 8231-E2D, 8268-E1D
- 8202-E4B, 8202-E4C, 8202-E4D
- 8205-E6B, 8205-E6C, 8205-E6D
- 8233-E8B, 8236-E8C
- 8248-L4T, 8408-E8D, 9109-RMD
- 8412-EAD, 9117-MMB, 9117-MMC, 9117-MMD
- 9179-MHB, 9179-MHC, 9179-MHD
- Expansion units: 5803, 5873
For slot priorities and maximum adapter counts, consult the PCI adapter placement guidelines for your specific system.
Warranty
60 days limited warranty.
